GIGABYTE Z790 AORUS PRO X motherboard

GIGABYTE Z790 AORUS PRO X motherboard
-10%

Product ID: 55

SKU Code:

GIGABYTE Z790 AORUS PRO X

Specifications:

Form factor: Standard-ATX
Socket: LGA 1700
Supported memory type: DDR5
Number of power phases: 18+1+2
Intel Chipset: Intel Z790
All Specifications

~~$579~~

$521

Add To Favorites

Compare

The GIGABYTE Z790 AORUS PRO X motherboard features massive cooling radiators with decorative elements and the AORUS series logo. RGB lighting supports programmable color palette and lighting effects via the app. Reinforced element base, 8-layer printed circuit board and 18+1+2 phase power subsystem guarantee uninterrupted operation under different computing loads.

GIGABYTE Z790 AORUS PRO X supports 13th and 14th generation Intel processors. There are 4 DIMM DDR5 slots for connecting up to 192 GB of RAM. Discrete graphics adapters can be installed using 3 PCI-E x16 slots. There are 5 M.2 connectors and 4 SATA slots available for HDD/SSD storage devices. Internet access capabilities are provided by a Wi-Fi 7 wireless module and a wired controller with a speed of 5 Gbps.

Seller/manufacturer warranty	36 months.
Type	motherboard
Model	GIGABYTE Z790 AORUS PRO X
Color	white
Form factor	Standard-ATX
Height	305 mm
Width	244 mm
Socket	LGA 1700
Supported memory type	DDR5
Supported memory form factor	DIMM
Number of memory slots	4
Number of memory channels	2
Maximum memory	192 GB
Maximum memory frequency (JEDEC / non-overclocked)	4800 MHz
Overclocked RAM frequency	5200 MHz, 5400 MHz, 5600 MHz, 5800 MHz, 6000 MHz, 6200 MHz, 6400 MHz, 6600 MHz, 6800 MHz, 7000 MHz, 7200 MHz, 7400 MHz, 7600 MHz, 7800 MHz, 7900 MHz, 7950 MHz, 8000 MHz, 8200 MHz, 8266 MHz
PCI Express Version	5.0
PCIe x16 slots	1 x PCIe 3.0 (in x4 mode), 1 x PCIe 4.0 (in x4 mode), 1 x PCIe 5.0 (in x16 mode)
SLI/CrossFire support	no
Number of cards in SLI / Crossfire	no pcs.
Number of PCI-E x1 slots	no
NVMe support	yes
PCI Express drive version	5.0
Number of M.2 connectors	5
M.2 (M) slots, PCIe processor lines	1 x 2280/22110 (PCIe 4.0 x4), 1 x 2580/25110 (PCIe 5.0 x4)
M.2 (M) slots, PCIe chipset lines	1 x 2280 (PCIe 4.0 x4), 1 x 2280 (SATA/PCIe 4.0 x4), 1 x 2280/22110 (PCIe 4.0 x4)
Number of SATA ports	4
SATA RAID operating mode	0, 1, 5, 10
Other drive connectors	no
USB Type-A Ports	2 x USB 2.0, 2 x USB 3.2 Gen 2, 4 x USB 3.2 Gen 1
USB Type-C ports	1 x USB 3.2 Gen 2, 1 x USB 3.2 Gen 2x2
Video outputs	1 x USB Type-C
Number of network ports (RJ-45)	1
Number of analog audio connectors	2
Digital audio ports (S/PDIF)	TOSLINK (S/PDIF optical)
SMA connectors (for Wi-Fi antenna)	yes
PS/2 ports	no
Internal USB Type-A connectors	1 x USB 3.2 Gen 1 (19 pin), 2 x USB 2.0 (9 pin)
Internal USB Type-C connectors	1 x USB 3.2 Gen 2, 1 x USB 3.2 Gen 2x2
CPU cooling power connectors	1 x 4 pin (cooler), 1 x 4 pin (cooler/pump)
Combined connectors for fans and LSS pump (4 pin)	2
Case fan headers (3 pin)	no
Connectors 5V-D-G (3 pin) for ARGB backlight	3
Connectors 12V-G-R-B (4 pin) for RGB backlight	1
M.2 (E) connector for wireless modules	yes
RS-232 (COM) connector	no
LPT interface	no
Sound design	7.1
Sound adapter chipset	Realtek ALC1220-VB
Network adapter speed	5 Gbps
Wi-Fi standard	7 (802.11be)
Bluetooth version	5.3
Wireless adapter	MediaTek RZ738
Main power connector	24 pin
CPU power connector	2 x 8 pin
Number of power phases	18+1+2
Passive cooling	5 x M.2 slot, VRM zone, chipset
Active cooling	no
Buttons on board	Q-Flash Plus button, reset button
Illumination of board elements	yes
Backlight Sync Software	GIGABYTE RGB Fusion
Additional features	2 connectors for connecting expansion cards with Thunderbolt support, 2 fan power connectors combined with pump power, Intel XMP support
Contents	2 x SATA cable, Wi-Fi antenna, documentation, front panel connector
Weight with box	1.85 kg
Case fan headers (4 pin)	4
Box length	34 cm
Box width	27 cm
Box height	8.2 cm
Intel Chipset	Intel Z790
Compatible Intel processor cores	Alder Lake, Raptor Lake, Raptor Lake Refresh
Number of PCB layers	8
Other rear connectors	1 x DisplayPort (in)
